Home server project 2021

Introduction

One of the items on my long term to-do list was to put my old hard drive collection to use by creating a network attached storage (NAS) machine. Over several upgrades over the past few years, I had amassed several 500gb-1tb drives both in 2.5' and 3.5' varieties that were collecting dust. The question quickly became- what was the cheapest and most cost effective way to build a NAS?. Specifically, many of the off the shelf solutions such as Synology carried out the duties of a NAS quite well; however, came with many downsides including the lack of multiple drive bays and quickly rising expense depending on how many drives it supported. Additionally, the many JBOD (just a bunch of disks) platforms that exist, despite being fairly cheap and supporting multiple drives, simply lack the network utility that a modern NAS can provide.

Parts

I quickly realized during my research that there simply weren't any off the shelf solutions on the market that would fit my requirements of: inexpensive, ability to utilize multiple small drives, and reasonable performance. At this point I had decided to build my own based on the Open Media Vault (OMV) platform. Based on Debian, OMV offers a plethora of features that any any modern off the shelf NAS will provide, although, with a slightly less intuitive user interface. The following is a breakdown of the parts I used and total cost.

Case: iStarUSA D213-mATX 2U Rackmount case ($0, purchased several years ago at NewEgg ~$45 USD)
PSU: 500W OCz ($0)
CPU: Intel G5400 ($54 @ Microcenter)
Motherboard: Gigabyte B365 DS3H ($70 @ Microcenter)
Memory: Crucial 8GB DDR4 ($25 @ Amazon)
Harddrives: Inland 128gb SATA SSD ($25 @ Microcenter) and $0 for 5tb of storage (5 drives ranging from 500gb-2tb)
Case fans: 80mm intake fans (~$6 @ Amazon)
Software: $0
Total: $186

As you can see, I managed to re-use many of the components I had laying around; however, even if I had bought all the components at the time of building my total cost would have still been in the $250-270 range which is still way beneath the price of the remotely comparable Synology DS220+ which is going for $299 on Amazon at the time of writing this article.

Part DS220+ Custom
CPU J4025 @ 2.0Ghz 2 threads Pentium Gold G5400 @ 3.7Ghz 4 threads
Memory 2gb DDR4 8gb DDR4
Storage 2 drive bays 6 SATA connectors → 6 potential drive bays
Network 2x1gb LAN 1x1gb LAN

Pros/Cons

Being the closest comparison off the shelf competitor, I used the DS220+ as my comparison point. From a performance, memory and storage aspect, my custom build was both cheaper and faster. Not to mention it also gives me the ability to replace and upgrades parts in the future as I see fit.

Now what are some downsides? I would be a liar if I said setting up OMV was anywhere near as simple and polished a process as Synology is. Unfortunately, despite all the developers best efforts, OMV is still a community developed project that still shows its roughness around the edges. Below are some of the issues I ran into while setting up the software.

  1. Upon installation finishing, I couldn't access the web gui despite the installer claiming I should be able to. This required me to connect via head and run omv-firstaid command from the terminal in order to reset the web gui as well as declare a static IP address.
  2. The process of setting up hard drives, creating a pool between the drives and creating shared folders is far from obvious. This process once again is made far simpler in Synology and just works. I plan to write a summary article on this soon to simply things for myself in the future.
  3. Upgrading drives can also result in unexpected issues. The week after installing OMV, I had upgraded one of my 500gb drives to a 4tb drive due to SMART errors suggesting the former would fail soon. I unmounted the drive and shut down the machine thinking a simple swap would be painless. Unfortunately I was wrong. OMV had issues booting and being a headless machine, as soon as I couldn't access the web gui I knew something was wrong. After an hour trouble shooting after connecting via head to the machine and being unsuccessful in fixing the issue; I ended up just re-installing the entire OS which fixed the issue. I doubt these kinds of issues plague Synology.

Summary

If you're in the market for a NAS and are even moderately technically capable (or willing to learn/experiment) I highly recommend going the custom route. If you want to build your own machine but want a bit more of a polished experience, I would recommend buying a copy of Unraid which is basically a significantly polished version of Linux NAS software devoid of the rough edges a community project like OMV has. I have a separate Unraid server and can attest to its quality. This all being said, OMV is an rock solid platform. Once up and running, the server chews through any task I throw at it. I currently have a docker instance running Plex which is able to transcode one or two 4K streams without a hiccup. I would bet the DS220+ can barely handle one.


Pelican markdown header snippet

Some of you may have noticed that the blog software I use is called Pelican- a static file based blog generator. Other similar pieces of software include Hugo and Jekyll. I prefer Pelican due to my preference for Python. One issue I encountered when writing articles in markdown for pelican was remembering the header for the markdown files. A simple fix for this is to use VSCode to write your articles and to create a vscode snippet for the header. I have put mine below as an example. Type pelhead to trigger the snippet.

{
"Pelican Header": {
    "prefix": "pelhead",
    "body": [
        "Title:",
        "Date: $CURRENT_YEAR-$CURRENT_MONTH-$CURRENT_DATE $CURRENT_HOUR:$CURRENT_MINUTE,
        "Category:",
        "Tags:",
        "Authors: Your Name Here",
        "Summary:"
    ],
    "description": "Pelican header"
    }
}

Output:

Title:
Date:
Category:
Tags:
Authors: Your Name Here
Summary:

Fast way to merge MP3 files together

This is a quick tutorial on merging mp3 files together. Like many seemingly trivial computing tasks that one would imagine are easy to perform in the year 2021 this is remarkably not easy to do. This is the fastest route I discovered and I hope it's helpful.

Requirements
1. Brew
2. MacOS

Steps
Open terminal or iTerm and run brew install -v mp3wrap id3lib ffmpeg to install all the required packages

Run mp3wrap temp.mp3 combinedme1.mp3 combineme2.mp3 ... (... can include as many mp3 files as you need to combine)

Next run ffmpeg to copy the mp3s together into a single file ffmpeg -i temp.mp3 -acodec copy combined.mp3

Now copy your tags over from the first mp3 file id3cp combineme1.mp3 combined.mp3

Delete the temporary files rm temp.mp3

Now you have a neatly combined combined.mp3. If you wish to edit the metadata of the mp3 I recommend using Squeed.
